Cisco IR809 Product Overview

DescriptionActivityLED
Off — Modem not powered on On — Modem is powered on and
connected but not transmitting or receiving Slow Blink — Modem
is powered on and searching for connection
Fast Blink — Modem is transmitting or receiving.
Wireless WAN
Activity
WWAN
The RSSI LEDs are a 3 LED bar graph to indicate signal strength.
Their functionality is described in the RSSI LEDs table below.
Received Signal
Strength Indication
RSSI
Off — No USIM
Green — USIM installed and active
SIM cardsSIM0/SIM1
Table 2: RSSI LEDs
RSSI (0)RSSI (1)RSSI (2)RSSI
Green/AmberGreenGreen
OffOffOff< -110dBm
On - AmberOffOff-110 to
-90dBm
On - GreenOffOff-90 to -75dBm
On - GreenOn -
Green
Off-75 to -60dBm
On - GreenOn -
Green
On -
Green
> -60dBm
SKU Information
The following table lists the different SKUs available for the Cisco 809 Integrated Services Router. All SKUs
support external antenna.
Table 3: Supported SKUs for Cisco IR809s
DescriptionSKU ID
Multimode 4G/3G/2G connectivity to cellular networks operating in LTE 1900 MHz (band 2 PCS), 1700/2100
MHz (band 4 AWS), 850 MHz (band 5), 700 MHz (band 17) and 1900 MHz (band 25 extended PCS)
frequencies; backward-compatible with UMTS and HSPA+: 850 MHz (band 5), 900 MHz (band 8), 1900
MHz (band 2 PCS), and 1700/2100 MHz (band 4 AWS).
IR809G-LTE-NA-K9
Multimode 4G/3G/2G connectivity to cellular networks operating in LTE 700 MHz (band 13), 1700/2100
MHz (band 4 AWS), or 1900 MHz (band 25 extended PCS) frequencies; backward-compatible with EVDO
Rev A/CDMA 1x BC0, BC1, BC10.
IR809G-LTE-VZ-K9
Product Overview
7
Product Overview
SKU Information
