Outdoor Cisco Aironet Dual-Band Omnidirectional Antenna and Access Point for Remote and Indoor Use Scenario

Table 8: Outdoor Dual-Band Omnidirectional Antenna and Access Point for Remote and Indoor Use Scenario

DescriptionItem

4 x Cisco Aironet dual-band AIR-ANT2547V-N or

AIR-ANT2547VG-N omnidirectional antennas mounted

remotely outdoors, with the access point located remotely,

indoors, or enclosed.

Antenna Arrangement

IW3702-2E-x-K9, IW3702-4E-x-K9, IW3702-2E-UXK9,

IW3702-4E-UXK9

Access Point

You need:

•

4 x DC pass, N(f)-N(f) lightning arrestors. Cisco PID

CGR-LA-NF-NF.

Lightning arrestors must be appropriately

grounded to infrastructure system ground

designed to conduct lightning currents to Earth

ground.

This configuration assumes that the lightning

arrestor is mounted on a building or enclosure

penetration panel, and that it is interfaced on

both sides with N(m) cables.

Note

•

4 x N(f) to N(f) RF adapters. Cisco PID

AIR-ACC370-NF-NF.

Adapter and/or Lightning Arrestor

This configuration assumes that there is an N(m) to N(m) cable

connected between the lightning arrestor and the Access Point.

For indoor cable routing, the deployment must balance the

requirements of Fire Code, Electrical Code, and any other

applicable regulations, versus RF cable type, cost, RF cable

length, and RF cable insertion loss.

Indoor Cable
