Cisco IW3702 User Manual

DescriptionItem
1 x Cisco Aironet AIR-ANT2513P4M-N four-port dual-band
polarization-diverse array antenna is required. The antenna
specifications are:
•
2.4-2.5 GHz, 5.15-5.925 GHz dual-band WiFi operating
frequency ranges
•
13 dBi peak gain
•
Type N(f) connector
•
IP67 rated, -40 to 185°F (-40°C to 85°C) operating
temperature range
•
Cisco PID AIR-ANT2513P4M-N
Antenna
Indoor Cisco Aironet Four-Element MIMO Dual-Band Ceiling Mount Omnidirectional Antenna and Access Point
Table 13: Indoor Four-Element MIMO Dual-Band Ceiling Mount Omnidirectional Antenna and Access Point
DescriptionItem
1 x Cisco Aironet AIR-ANT2524V4C-R indoor four-element
MIMO dual-band ceiling mount omnidirectional antenna
directly connected to the access point. Antennas are indoor
only.
Antenna Arrangement
IW3702-2E-x-K9, IW3702-4E-x-K9, IW3702-2E-UXK9, or
IW3702-4E-UXK9
Access Point
You need:
•
4 x N(m) to RP-TNC (jack), RF coax adapters. Cisco
PID AIR-ACC370-NM-RF.
No lightning arrestors are
required.
Note
Adapter and/or Lightning Arrestor
For indoor cable routing, the deployment must balance the
requirements of Fire Code, Electrical Code, and any other
applicable regulations, versus RF cable type, cost, RF cable
length, and RF cable insertion loss.
Indoor Cable
N/AOutdoor Cable
36

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
