Cisco IW3702 User Manual

DescriptionItem
1 x Cisco Aironet AIR-ANT2524V4C-R indoor four-element,
MIMO, dual-band ceiling mount omnidirectional antennas are
required. The antenna specifications are:
•
2400-2500 MHz, 5150-5850 MHz dual-band WiFi
operating frequency range
•
MIMO operation
•
2 dBi (2.4 GHz), 4 dBi (5.8 GHz) gain
•
4 x integrated cables with RP-TNC (plug) connector
•
Indoor operation, 32 to 133°F (0 to 56°C) operating
temperature range
•
Cisco PID AIR-ANT2524V4C-R=
Antenna
Indoor or Outdoor Cisco Aironet Dual-Band MIMO Wall-Mounted Omnidirectional Antenna and Access Point
Table 14: Indoor or Outdoor Dual-Band MIMO Wall-Mounted Omnidirectional Antenna and Access Point
DescriptionItem
1 x Cisco Aironet AIR-ANT2544V4M-R dual-band MIMO
wall-mounted omnidirectional antenna directly connected to
the access point antenna connector.
Antenna Arrangement
IW3702-2E-x-K9, IW3702-4E-x-K9, IW3702-2E-UXK9 or
IW3702-4E-UXK9
Access Point
You need:
•
4 x N(m) to RP-TNC (jack), RF coax adapters. Cisco
PID AIR-ACC370-NM-RF
No lightning arrestors are
required.
Note
Adapter and/or Lightning Arrestor
N/AIndoor Cable
N/AOutdoor Cable
37

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
