Page #38 background imageLoading...
Page #38 background image
DescriptionItem
1 x Cisco Aironet AIR-ANT2544V4M-R dual-band MIMO
wall-mounted omnidirectional antennas are required. The
antenna specifications are:
2400-2484 MHz, 5150-5850MHz dual-band WiFi
operating frequency range
Bands 5150-5350MHz are not supported for
outdoor installations within Regulatory Domain E
MIMO, omnidirectional operation
4 dBi (2.4 GHz), 4 dBi (5.8 GHz) gain
Indoor or outdoor operation, -40 to 158°F (-40 to +70°C)
operating temperature range
4 x integrated cables with RP-TNC (plug) connector
Cisco PID AIR-ANT2544V4M-R
Antenna
Outdoor Cisco Aironet Dual-Band MIMO Wall-Mounted Omnidirectional Antenna and Access Point for Indoor Use Scenario
Table 15: Outdoor Dual-Band MIMO Wall-Mounted Omnidirectional Antenna and Access Point for Indoor Use Scenario
DescriptionItem
1 x Cisco Aironet AIR-ANT2544V4M-R dual-band MIMO
wall-mounted omnidirectional antenna mounted remotely
outdoors.
Antenna Arrangement
IW3702-2E-x-K9, IW3702-4E-x-K9, IW3702-2E-UXK9 or
IW3702-4E-UXK9
Access Point
4 x DC pass, N(f)-N(f) lightning arrestors, Cisco PID
CGR-LA-NF-NF.
Lightning arrestors must be appropriately grounded
to infrastructure system ground designed to conduct
lightning currents to Earth ground.
This configuration assumes that the lightning arrestor
is mounted on a building or enclosure penetration
panel, and that it is interfaced on both sides with N(m)
cables.
Note
Adapter and/or Lightning Arrestor
38
