DescriptionItem
This configuration assumes that there is an N(m) to N(m) cable
connected between the lightning arrestor and the Access Point.
For indoor cable routing, the deployment must balance the
requirements of Fire Code, Electrical Code, and any other
applicable regulations, versus RF cable type, cost, RF cable
length, and RF cable insertion loss.
Indoor Cable
Select from:
4 x N(m)-R/A to RP-TNC (jack), LMR-240-DB, 10 ft.
cable. Cisco PID CAB-L240-10-N-R
4 x N(m)-R/A to RP-TNC (jack), LMR-400-DB, 20 ft.
cable. Cisco PID CAB-L400-20-N-R
Outdoor Cable
1 x Cisco Aironet AIR-ANT2544V4M-R dual-band MIMO
wall-mounted omnidirectional antenna is required. The antenna
specifications are:
2400-2484 MHz, 5150-5850MHz dual-band WiFi
operating frequency range
MIMO, omnidirectional operation
4 dBi (2.4 GHz), 4 dBi (5.8 GHz) gain
Indoor or outdoor operation, -40 to 158°F (-40 to +70°C)
operating temperature range
4 x integrated cables with RP-TNC (plug) connector
Cisco PID AIR-ANT2544V4M-R
Antenna
Indoor or Outdoor Cisco Aironet Dual-Band MIMO 4-Element Patch Antenna and Access Point
Table 16: Indoor or Outdoor Dual-Band MIMO 4-Element Patch Antenna and Access Point
DescriptionItem
1 x Cisco Aironet AIR-ANT2566P4W-R dual-band WiFi
MIMO 4-element patch antenna directly connected to the
access point.
Antenna Arrangement
IW3702-2E-x-K9, IW3702-4E-x-K9, IW3702-2E-UXK9 or
IW3702-4E-UXK9
Access Point
39
