Cisco IW3702 User Manual

DescriptionItem
You need:
•
4 x N(m) to RP-TNC (jack), RF coax adapters. Cisco
PID AIR-ACC370-NM-RF.
No lightning arrestors are
required.
Note
Adapter and/or Lightning Arrestor
N/AIndoor Cable
N/AOutdoor Cable
1 x Cisco Aironet AIR-ANT2566P4W-R dual-band WiFi
MIMO 4-element patch antenna is required. The antenna
specifications are:
•
2400-2484 MHz, 5150-5850 MHz operating frequency
range
•
WiFi, MIMO operation
•
Single polarization
•
6dBi (2.4 GHz), 6 dBi (5.8 GHz) gain
•
IP54 rated, indoor or outdoor operation, -40 to 158°F
(-40 to +70°C) operating temperature range
•
4 x integrated cables with RP-TNC (plug) connector
•
Cisco PID AIR-ANT2566P4W-R
Antenna
Outdoor Cisco Aironet Dual-Band MIMO 4-Element Patch Antenna and Access Point for Indoor or Enclosed Use Scenario
Table 17: Outdoor Dual-Band MIMO 4-Element Patch Antenna and Access Point for Indoor or Enclosed Use Scenario
DescriptionItem
1 x Cisco Aironet AIR-ANT2566P4W-R dual-band WiFi
MIMO 4-element patch antenna mounted remotely outdoors,
access point is indoors.
Antenna Arrangement
IW3702-2E-x-K9, IW3702-4E-x-K9, IW3702-2E-UXK9 or
IW3702-4E-UXK9
Access Point
40

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
