Cisco IW3702 User Manual

DescriptionItem
4 x DC pass, N(f)-N(f), lightning arrestors. Cisco PID
CGR-LA-NF-NF.
Lightning arrestors must be appropriately grounded
to infrastructure system ground designed to conduct
lightning currents to Earth ground.
This configuration assumes that the lightning arrestor
is mounted on a building or enclosure penetration
panel, and that it is interfaced on both sides with N(m)
cables.
Note
Adapter and/or Lightning Arrestor
This configuration assumes that there is an N(m) to N(m) cable
connected between the lightning arrestor and the Access Point.
For indoor cable routing, the deployment must balance the
requirements of Fire Code, Electrical Code, and any other
applicable regulations, versus RF cable type, cost, RF cable
length, and RF cable insertion loss.
Indoor Cable
Select from:
•
4 x N(m)-R/A to RP-TNC (jack), LMR-240-DB, 10 ft.
cables. Cisco PID CAB-L240-10-N-R
•
4 x N(m)-R/A to RP-TNC (jack), LMR-400-DB, 20 ft.
cables. Cisco PID CAB-L400-20-N-R
Outdoor Cable
1 x Cisco Aironet AIR-ANT2566P4W-R dual-band WiFi
MIMO 4-element patch antenna is required. The antenna
specifications are:
•
2400-2484 MHz, 5150-5850 MHz operating frequency
range
•
WiFi, MIMO operation
•
Single polarization
•
6dBi (2.4 GHz), 6 dBi (5.8 GHz) gain
•
IP54 rated, indoor or outdoor operation, -40 to 158°F
(-40 to +70°C) operating temperature range
•
4 x integrated cables with RP-TNC (plug) connector
•
Cisco PID AIR-ANT2566P4W-R
Antenna
41

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
