Cisco IW3702 User Manual

DescriptionItem
1 x Cisco Aironet AIR-ANT2566D4M-R Dual-Band
Polarization-Diverse Directional Array antenna is required.
The antenna specifications are:
•
2400-2484 MHz, 5150-5850 MHz operating frequency
range
•
WiFi, MIMO operation
•
Dual polarization
•
6dBi (2.4 GHz), 6 dBi (5.8 GHz) gain
•
IP67 rated, indoor or outdoor operation, -40 to 158°F
(-40 to +70°C) operating temperature range
•
4 x integrated cables with RP-TNC (plug) connector
•
Cisco PID AIR-ANT2566D4M-R
Antenna
Outdoor Single Band Antennas in Flexible Antenna Port (Flex Port) Configuration and Access Point
Table 20: Outdoor Single band antennas in Flexible Antenna Port (Flex Port) configuration and Access Point
DescriptionItem
1 x Cisco Aironet 2.4 GHz 13-dBi Directional Antenna
AIR-ANT2413P2M-N dual port antenna connected to IW3702
ports “A” and “B” together with
1 x Cisco Aironet 5 GHz 14-dBi Directional Antenna
AIR-ANT5114P2M-N dual port antenna connected to IW3702
ports “C” and “D”.
Access point can be located outdoors, indoors, or located in
an enclosure.
Extension cables may be needed depending on distance
between antennas and the access point.
Antenna Arrangement
IW3702-2E-x-K9, IW3702-4E-x-K9, IW3702-2E-UXK9 or
IW3702-4E-UXK9
Access Point
44

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
