DescriptionItem
Select from the following list, and choose appropriate quantity
according to the descriptions above.
• N(m)-R/A to N(m)-STR, LMR-400-DB, 5’ RF cable,
Cisco PID: CAB-L400-5-N-N
• N(m)-STR to N(m)-STR, LMR-400-DB, 5’ RF cable,
Cisco PID: CAB-L400-5-N-NS
• N(m)-R/A to N(m)-STR, LMR-400-DB , 10’ RF cable,
Cisco PID: AIR-CAB010LL-N
• N(m)-R/A to N(m)-STR, LMR-400-DB, 20’ RF cable,
Cisco PID: CAB-L400-20-N-N
• N(m)-R/A to N(m)-STR, LMR-600-DB, 30’ RF cable,
Cisco PID: CAB-L600-30-N-N
• 4 x N(m)-STR to N(m)-STR, LMR-400-DB, 25’ RF cable
with petrochemical and oils resistance, Cisco PID
AIR-CAB025HZ-N
Outdoor Cable
1 x Cisco Aironet 2.4 GHz 13-dBi Directional Antenna
AIR-ANT2413P2M-N dual port antenna connected to IW3702
ports “A” and “B”, together with:
1 x Cisco Aironet 5 GHz 14-dBi Directional Antenna
AIR-ANT5114P2M-N dual port antenna connected to IW3702
ports “C” and “D”.
AIR-ANT2413P2M-N antenna specifications:
2.4 GHz 13-dBi Directional Antenna, dual port, dual
polarization.
http://www.cisco.com/c/en/us/td/docs/wireless/antenna/
installation/guide/ant2413p2m-n.html
AIR-ANT5114P2M-N antenna specifications:
5-GHz 14-dBi Directional Antenna, dual port, dual polarization.
http://www.cisco.com/c/en/us/td/docs/wireless/antenna/
installation/guide/ant5114p2m-n.html
Due to cable losses reducing antenna gain, the 14dBi
AIR-ANT5114P2M-N should be specified as 13dBi
in the CLI, when specifying 5GHz antenna gain
selection of IW3702.
Note
Antenna
IW3702 Flexible Antenna Port
•
Supports either dual-band or single band antennas on the same platform.
47

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
