DescriptionItem
For example, if AIR-ANT2413P2M-N needs to be extended
by 5ft, and AIR-ANT5114P2M-N needs to be extended by
20ft, then choose:
2 x AIR-ACC370-NF-NF adapters, plus 2 x CAB-L400-5-N-N
for the AIR-ANT2413P2M-N dual port antenna,
2 x AIR-ACC370-NF-NF adapters, plus 2 x
CAB-L400-20-N-N for the AIR-ANT5114P2M-N dual port
antenna.
Selection:
•
N(f) to N(f) RF adapter: Cisco PID,
AIR-ACC370-NF-NF
• N(m)-R/A to N(m)-STR, LMR-400-DB , 5’ RF cable,
Cisco PID: CAB-L400-5-N-N,
• N(m)-STR to N(m)-STR, LMR-400-DB , 5’ RF cable,
Cisco PID: CAB-L400-5-N-NS
• N(m)-R/A to N(m)-STR, LMR-400-DB , 10’ RF-cable,
Cisco PID: AIR-CAB010LL-N
• N(m)-R/A to N(m)-STR, LMR-400-DB, 20’ RF cable,
Cisco PID: CAB-L400-20-N-N
• N(m)-R/A to N(m)-STR, LMR-600-DB, 30’ RF cable,
Cisco PID: CAB-L600-30-N-N
• 4 x N(m)-STR to N(m)-STR, LMR-400-DB, 25’ RF cable
with petrochemical and oils resistance, Cisco PID
AIR-CAB025HZ-N
For indoor cable routing, the deployment must balance the
requirements of Fire Code, Electrical Code, and any other
applicable regulations, versus RF cable type, cost, RF cable
length, and RF cable insertion loss.
Indoor Cable
