Cisco IW3702 User Manual

Table 2: Status LED
System StateLED ColorMessage Type
DRAM memory test in progress.Blinking pinkBoot loader status
DRAM memory test OK.
Board initialization in progress.
Initializing flash file system.
Flash memory test OK.
Initializing Ethernet.
Ethernet OK.
Starting Cisco IOS.
Initialization successful.
Normal operating condition but no
wireless client association.
GreenClient association status
Normal operating condition with at least
one wireless client association.
Blue
Software upgrade in progress.Blinking blueOperational status
Discovery/join process in progress.Cycling green-red-off
Access point location command invoked.Rapidly cycling blue-green-red
Ethernet link not operational.Blinking red
Configuration recovery in progress
(MODE button pushed for 2 to 3
seconds).
Blinking blueBoot loader warnings
Ethernet failure or image recovery
(MODE button pushed for 20 to 30
seconds).
Red
Image recovery in progress (MODE
button released).
Blinking pink
9

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
