Cisco MDS 9000 Family Port Analyzer Adapter Installation and Configuration Note
OL-9077-01
Installing the Port Analyzer Adapter
Installing the Port Analyzer Adapter
Note Before you install, operate, or service this equipment, read the Regulatory Compliance and Safety
Information for the Cisco MDS 9000 Family for important safety information.
To install the Cisco MDS 9000 Family Port Analyzer Adapter, follow these steps:
Step 1 Configure the DIP switch settings at the rear of the adapter. See Table 2 on page 7 for DIP switch settings
and modes of operation.
Step 2 Connect the AC power converter to the rear of the adapter.
Step 3 Connect the left (Fibre Channel) port on the adapter to the Fibre Channel SD port on the switch (see
Figure 6). Use regular multimode fiber with LC to LC connectors (see Figure 7). Attach one LC
connector to the switch and another LC connector to the adapter.
