Hardware Description
LED Descriptions
The PAA has five LEDs on its faceplate (see Figure 2).
Table 1 lists the LEDs, their conditions, and what the conditions indicate.
Table 1 LED Descriptions
LED Type Status Description
Status Off Either the power to the adapter is off or there is a power
failure. The adapter cannot power up.
Red Power is up, but there is some other failure.
To attempt to fix the failure, power cycle the adapter by
powering off and waiting for more than four seconds
before powering on. To power cycle, disconnect the
power cord from the wall rather than from the adapter.
Green The adapter is functioning correctly.
Fibre Channel Link Off The Fibre Channel link is down.
Green The Fibre Channel link is up.
Fibre Channel Speed Off The Fibre Channel link is programmed in 1-Gbps mode.
Green The Fibre Channel link is programmed in 2-Gbps mode.
100-Mbps Ethernet Off The Ethernet link is down. The link speed might not be
negotiated.
The LED is off when Ethernet is configured in 1-Gbps
mode.
Green The Ethernet link is up in 100-Mbps mode.
Blinking green Ethernet frames are being transmitted on the Ethernet
link.
1-Gbps Ethernet Off The Ethernet link is down. The link speed might not be
negotiated.
The LED is off when Ethernet is configured in
100-Mbps mode.
Green The Ethernet link is up in 1-Gbps mode.
Blinking green Ethernet frames are being transmitted on the Ethernet
link.
