StateStatusColorFunctionLocationIndicator
No input to the PSU.OffGreen
PSU
input/output
Faceplate of each
PSU
PSU Status
PSU output is OK.Solid on
PSU output is not OK, but
input is OK.
Blinking
One of the following
conditions exists in the PSU:
Over voltage
Over current
Over temperature
Fan failure.
Solid on
AmberPSU
Operation
PSU has a fault, but is still
operational.
Blinking
PSU is operating normally.Off
The following table describes the Ethernet port LEDs for a Cisco MDS 9396T switch.
StateStatusLED
Position
There is no link.OffLeft
Indicates a physical
link.
Solid Green
There is no activity.
OffRight
Indicates activity.Blinking
Green
The following table describes the Fibre Channel port LEDs for a Cisco MDS 9396T switch.
StateStatus
The link is up.Solid Green
The link is up and the port beacon is active.Regular Blinking Green
The link is up (indicates traffic on the port).Intermittent Blinking
Green
The link is disabled by the software.Solid Orange
A faulty condition exists.Blinking Orange
No link.Off
Cisco MDS 9396T Multilayer Fabric Switch Hardware Installation Guide
13
Product Overview
Switch LEDs
