Preinstallation Guidelines
Airflow Considerations
The switch comes with fan modules and power supply units that have either port-side intake or port-side
exhaust airflow for cooling the switch. If you are orienting the switch with the FC ports facing a cold aisle,
make sure that the switch has a port-side intake fan and power supply modules with red colorings. If you are
orienting the switch with the fan and power supply modules facing a cold aisle, make sure that the switch has
port-side exhaust fan and power supply units with blue colorings. All fan modules and power-supply modules
must have the same direction of airflow.
Connection Guidelines for AC-Powered Systems
To connect to the Cisco MDS 9396T switch AC power supply units to the site power source, follow these
guidelines:
• For power redundancy, each power supply should be connected to a separate power feed (at a minimum,
separate branch circuits).
• Circuits should be sized according to local and national codes.
• The AC power receptacles that are used to power the chassis must be the grounding type. The grounding
conductors that connect to the receptacles should connect to protective earth ground in the service
equipment.
Installation Guidelines
Follow these guidelines when installing the Cisco MDS 9396T Switch:
• Plan your site configuration and prepare the site before installing the switch.
• Each new switch requires a license; see the Cisco MDS 9000 Family NX-OS Licensing Guide for
instructions on installing a license.
• Ensure there is adequate space around the switch to allow for servicing the switch and for adequate
airflow (airflow requirements are listed the Technical Specifications section).
• Ensure the air-conditioning meets the heat dissipation requirements listed the Technical Specifications
section.
• Ensure the cabinet or rack meets the requirements listed in the Cabinet and Rack Requirements section.
• Ensure that the cabinet or rack meets the requirements listed in the Cabinet and Rack Requirements
section.
If the front cabinet mounting rails are not offset from the front door or bezel panel by a minimum of 3 inch
(7.6 cm), and a minimum of 5 inch. (12.7 cm), respectively, and cable management brackets are installed on
the front of the chassis, the chassis should be mounted rear-facing to ensure the minimum bend radius for
fiber-optic cables.
Note
Cisco MDS 9396T Multilayer Fabric Switch Hardware Installation Guide
29
Installing the Cisco MDS 9396T Switch
Preinstallation Guidelines
