Cisco NCS 5500 Series Hardware Installation Guide

NCS 5516NCS 5508NCS 5504Component
3 to 6
NC55-5516-FC
Use only with
NC55-5516-FAN.
Caution
3 to 6
NC55-5508-FC
Use only with
NC55-5508-FAN.
Caution
3 to 6
NC55-5504-FC
Fabric Cards
3 to 6
NC55-5516-FC2
Use only with
NC55-5516-FAN2.
Caution
3 to 6
NC55-5508-FC2
Use only with
NC55-5508-FAN2.
Caution
During a system
upgrade from
Release 7.0.1 or
Release 7.0.2 to any
future release, the
NC55-5508-FC2
card reloads twice.
The reboot history
can be verified using
the show
reboot-history card
location <node-id>
command, in the
System Admin
Config mode.
Note
3
NC55-5516-FAN
Use only with
NC55-5516-FC.
Caution
3
NC55-5508-FAN
Use only with
NC55-5508-FC.
Caution
3
NC55-5504-FAN
Fan trays
3
NC55-5516-FAN2
Use only with
NC55-5516-FC2.
Caution
3
NC55-5508-FAN2
Use only with
NC55-5508-FC2.
Caution
108
4Power supplies:
• NC55-PWR-3KW-AC
• NC55-PWR-3KW-DC
• NC55-PWR-3KW-2HV
(3.15-kW HVAC/HVDC
dual-input)
Hardware Installation Guide for Cisco NCS 5500 Series Modular Routers
2
NCS 5500 Series Modular Router Overview
NCS 5500 Series Modular Routers

Cisco NCS 5500 Series Specifications

General

Series	NCS 5500
Category	Network Router
Operating System	Cisco IOS XR
Product Type	Modular Router
Form Factor	Rack-mountable
Purpose	High-performance routing for service providers and large enterprises
Interface Types	Ethernet
Redundancy	Redundant power supplies and fan trays
Port Density	Varies by model; high-density configurations available
Routing Protocols	BGP, OSPF, IS-IS, MPLS
Power Supply Options	AC and DC power supplies available
Management	CLI, SNMP, NETCONF
