Chapter 1 Overview
Cisco Nexus 6001 Switch
Chassis
The Cisco Nexus 6001 switch chassis is 1 RU, 1.75 inches (4.4 cm) tall, 17.3 inches (43.9 cm) wide, and
30 inches (76.2 cm) deep. The front of the switch is shown in Figure 1-1.
Figure 1-1 Front View of the Cisco Nexus 6001 switch
The rear of the Cisco Nexus 6001 switch chassis, is shown in Figure 1-2.
1 Two power supplies
2 Three fan modules
3 Management and Console inteface
