Chapter 1 Overview
Cisco Nexus 6001 Switch
Figure 1-2 Rear View of the Cisco Nexus 6001 switch
Power Supply
The Cisco Nexus 6001 switch uses a front-end power supply. The chassis has slots for tworedundant
power supplies. Power Supply options need to be configured with the base chassis. It needs minimum of
one power supply to operate. OIR is supported on the power supplies and the power supplies are hot
swappable. The Cisco Nexus 6001 supports front-to-back (port-side exhaust) and back-to-front airflow
(port-side intake). Table 1-1 lists the power supplies that you can order with a Cisco Nexus 6001 switch.
Note The 1100 W, AC/DC, back-to-front, power supply (PID: N55-PAC-1100W-B) is not supported on the
N6K-C6001-64T.
1 48 fixed SFP+ ports 2 4 QSFP+ ports
Table 1-1 Power Supplies for the Cisco Nexus 6001 switch
Part Number Power Supply
N55K-PAC-1100W Cisco Nexus 6001 PSU module, 100-240VAC 1100W, Front-to-Back (Port
Side Exhaust) Airflow
N55K-PAC-1100W-B Cisco Nexus 6001 PSU module, 100-240VAC 1100W, Back-to-Front (Port
Side Intake) Airflow
N55-PDC-1100W Cisco Nexus 1100 Watt DC front-to-back power supply
