Cable and Port Specifications
This appendix provides cable and port specifications for the Cisco Nexus 6000 Series switch.
This appendix includes the following sections:
• Cable RJ-45 Connector Pinouts, page C-1
• Console Port, page C-2
• Supported Power Cords and Plugs, page C-2
• Jumper Power Cord, page C-8
Cable RJ-45 Connector Pinouts
Table C-1 lists the pinouts for the RJ-45 connector on the console cable.
Table C-1 Cable Connector Pinouts
Signal Name P1, P1-45 Pins P2, DB-9 Pins Signal Name
RTS 1 8 CTS
DTR 2 6 DSR
TXD 3 2 ZXD
GND 4 5 GND
GND 5 5 GND
ZXD 6 3 TXD
DSR 7 4 DTR
CTS 8 7 RTS
