If different blade server models are inserted in a single chassis, install the chassis with the heaviest total weight
in the lowest possible RU space and proceed to install the progressively lighter chassis above it.
Chassis Installation and Cabling
Review the maximum supported chassis configurations mentioned previously and install the UCS 5108 Server
Chassis or UCS Mini chassis according to the instructions in the Cisco UCS 5108 Server Chassis Installation
Guide. Use the illustrations in this section as a guide to installing power cables and data cables.
Installing the L-Shaped Brackets
Before shipping a preracked UCS 5108 or UCS Mini blade server chassis, install the L-shaped brackets that
come in the Accessory Kit that ships with the UCS 5108 blade server chassis .
Procedure
Step 1 Install the UCS 5108 or UCS Mini blade server chassis.
Step 2 See the "Installation" chapter of the Cisco UCS 5108 Server Chassis Installation Guide.
Data Cables for the UCS 5108 Server Chassis
The following figure shows how a 40-Gbps Fabric Extender module connects to an external UCS 6332-16UP
Fabric Interconnect.
Cisco R42612 Rack and RP-Series Metered Input PDU Installation Guide
63
Integrating UCS Components in the Dynamic Rack
Chassis Installation and Cabling
