CHAPTER 6
Replacing Components
This chapter contains the following sections:
• Removing and Installing Side Panels, on page 43
• Removing and Installing Cisco R-Series Rack Doors, on page 44
• Using the Cabling Portholes, on page 47
Removing and Installing Side Panels
The Cisco R-Series Rack may come with side panels installed. Removing the side panels may make it easier
to install PDUs, servers, and other components.
Installing the panel is the reverse process of removing them. Complete the following steps to remove the side
panels from the rack.
Procedure
Step 1 Unlock both button locks with the provided key and then slide the latches toward each other to open the side
panels.
Cisco R42612 Rack and RP-Series Metered Input PDU Installation Guide
43
