Quality of Service (QoS)
Bandwidth Management
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 117
7
Configuring QoS Binding Policy
In the QoS Binding Table, you can configure QoS policy for upstream traffic.
STEP 1 Click Add Row.
STEP 2 Enter information in the following fields to add or edit policy settings:
Policy Name Name of policy.
Protocol Select the protocol from the drop-down list. (TCP &
UCP, TCP or UCP).
Source Port Select the source port from the drop down list. It
can be any port, a single port or port range.
Destination Port Select the destination port from the drop down list.
It can be any port, a single port or port range.
Source IP Select the source IP from the drop down list. It can
be any IP address, a single IP address or an IP
address range.
Destination IP Select the destination IP from the drop down list. It
can be any IP address, a single IP address or an IP
address range.
MAC Address Select the type of MAC address from the drop
down list. It can be Any or Single MAC address.
This is the MAC address of the source of this traffic.
VLAN ID Select the VLAN ID from the drop-down list. This is
the VLAN ID of the source of this traffic.
Available SSIDs Select the available SSIDs from the drop-down list.
This is the SSID of the source of this traffic.
Physical Port Select the port (1 -3 for RV132W or 1- 4 for
RV134W) from the drop-down list. This is the LAN
port of the source of this traffic.
Queue Set the priority (1 lowest to 4 highest) for the
selected category.
Rate Limit (Kbit/Sec): Enter the rate limit in Kbits per second.
