Cisco RV134W Administration Guide

Firewall
Internet Access Policy Configuration
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 95
5
• Address Range — Enter a range of IP addresses to which the rule applies to
in the Start and Finish fields
STEP 9 To log details for all packets that match this rule, select Always from the drop-
down list. For example, if an outbound rule for a schedule is selected as Block
Always, for every packet that tries to make an outbound connection for that
service, a message with the packet's source address and destination address
(and other information) is recorded in the log.
Enabling logging may generate a significant volume of log messages and is
recommended for debugging purposes only.
Select Never to disable logging.
NOTE When traffic is going from the LAN or DMZ to the WAN, the system requires
rewriting the source or destination IP address of incoming IP packets as they pass
through the firewall.
STEP 10 Rule Status - Check Enable to enable the new access rule.
STEP 11 Click Save.
Internet Access Policy Configuration
The device supports several options for blocking Internet access. You can block
all Internet traffic, block Internet traffic to certain PCs or endpoints, or block
access to Internet sites by specifying keywords to block. If these keywords are
found in the site's name (for example, web site URL or newsgroup name), the site is
blocked.
Adding or Editing an Internet Access Policy
To create an Internet access policy:
STEP 1 Select Firewall > Internet Access Policy.
STEP 2 Click Add Row.
STEP 3 Check Status Enable.
STEP 4 Enter a policy name for identification and management purposes.
