Cisco RV134W Administration Guide

Networking
Configuring LAN Settings
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 17
3
In the DSL Settings for PTM transfer mode (RV134W) enter the following
information:
In the Bridged Settings section for both the ATM and PTM (RV134W) transfer
modes, enter the following information:
In the Other Settings section for both the ATM and PTM (RV134W) transfer
modes, enter the following information:
DSL Modulation Select the DSL modulation from the
drop-down list. The default DSL
modulation is Multimode
(recommended).
Transfer Mode PTM
SRA (Seamless Rate Adaption) Check Enable or Disable to enable or
disable the SRA, a protocol which, by
decoupling the modulation and
framing layer, can change the
transmission data rate parameters
(applied by the modulation layer).
DSL Modulation Select the DSL modulation from the
drop-down list. The default DSL
modulation is Multimode
(recommended).
Ethernet LAN Ports Select the Ethernet LAN ports. (LAN1,
LAN2, LAN3 or LAN4 - [RV134W only]).
2.4G Wireless Ports Select SSID1 (default).
5G Wireless Ports (RV134W only) Select SSID1 (default).
VLAN & VLAN ID
If enabled, all outbound traffic through this interface is
tagged with the configured VLAN ID.
MTU (Maximum
Transmission Unit)
MTU is an advanced configuration that allows you to
determine the largest data size permitted on your
connection. Select Auto (default) or Manual to
configure manually.
