Cisco RV134W

Networking
Configuring LAN Settings
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 25
3
In the DSL Settings for the PTM transfer mode(RV134W), enter the following
information:
In the PPPoE Settings section for both the ATM and PTM (RV134W) transfer
modes, enter the following information:
SRA (Seamless Rate Adaption) Check Enable or Disable to enable or
disable the SRA, a protocol which, by
decoupling the modulation and
framing layer, can change the
transmission data rate parameters
(applied by the modulation layer).
DSL Modulation Select the DSL modulation from the
drop-down list. The default DSL
modulation is Multimode
(recommended).
Transfer Mode PTM
SRA (Seamless Rate Adaption) Check Enable or Disable to enable or
disable the SRA, a protocol which, by
decoupling the modulation and
framing layer, can change the
transmission data rate parameters
(applied by the modulation layer).
DSL Modulation Select the DSL modulation from the
drop-down list. The default DSL
modulation is Multimode
(recommended).
Username Enter the username.
Password Enter the password.
DNS Server Source Select Get Dynamically from ISP or Use These
DNS Servers to manually configure.
Static DNS 1 & 2 Enter the IP address of the primary and or
secondary Static DNS in the fields (Hint 1.2.3.4).
