Cisco RV134W Administration Guide

Networking
Configuring LAN Settings
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 57
3
STEP 3 Click Save.
Link The port speed. If no device is connected to the
port, this field displays Down.
Mode Select from the drop-down menu one of the
following port speeds:
• Auto Negotiation—The device and the
connected device select a common speed.
• 10Mbps Half—10 Mbps in both directions,
but only one direction at a time.
• 10Mbps Full—10 Mbps in both directions
simultaneously.
• 100Mbps Half—100 Mbps in both
directions, but only one direction at a time.
• 100Mbps Full—100 Mbps in both
directions simultaneously.
Flow Control Check to enable flow control for this port.
Flow control is the process of managing the rate of
data transmission between two nodes to prevent a
fast sender from outrunning a slow receiver. It
provides a mechanism for the receiver to control
the transmission speed, so that the receiving node
is not overwhelmed with data from the transmitting
node.
EEE Check this box to enable Energy-Efficient Ethernet
that reduces the consumption of power during
periods of low activity. This function is only
available on RV134W.

Cisco RV134W Specifications

General

Brand	Cisco
Model	RV134W
Category	Wireless Router
Language	English
