D14908.02 SX20 Administrator Guide TC6.0, JANUARY 2013. www.cisco.com — Copyright © 2012-2013 Cisco Systems, Inc. All rights reserved.
97
Cisco TelePresence SX20 Quick Set Administrator Guide
Video OSD InputMethod Cyrillic
Set the Cyrillic mode for the menu input language in the menus on screen.
Requires user role: ADMIN
Value space: <Off/On>
Off: Cyrillic mode is NOT available as a menu input language in the menus on screen.
On: Cyrillic mode is available as a menu input language in the menus on screen. This will
enable the setting Video OSD InputMethod InputLanguage.
Example:
Video OSD InputMethod Cyrillic: Off
Video OSD LoginRequired
Determine if the system should require the user to login before accessing the On Screen
Display (OSD). If enabled, the user must enter his username and his PIN. After the user has
logged in he can only execute to the configurations changes and commands allowed by his
Role.
Requires user role: ADMIN
Value space: <Off/On>
Off: No login to the OSD is required.
On: The user must log in to access the On Screen Display (OSD).
Example:
Video OSD LoginRequired: Off
Video AllowWebSnapshots
Allow or disallow snapshots being taken of the local input sources, remote sites and
presentation channel. If allowed, the web interface Call Control page will show snapshots both
when idle and in a call.
NOTE: This feature is disabled by default, and must be enabled from the On Screen Display
(OSD), from a directly connected Touch controller, or via the codec's serial port (USB port and
RS-232 adapter).
Requires user role: ADMIN
Value space: <Off/On>
Off: Capturing web snapshots is not allowed.
On: Web snapshots can be captured and displayed on the web interface.
Example:
Video AllowWebSnapshots: Off
Video Output HDMI [1,2] RGBQuantizationRange
All devices with HDMI outputs should follow the rules for RGB video quantization range defined
in CEA-861. Unfortunately some devices do not follow the standard and this configuration may
be used to override the settings to get a perfect image with any display. The default value is set
to Full because most HDMI displays expects full quantization range.
Requires user role: ADMIN
Value space: <Auto/Full/Limited>
Auto: RGB quantization range is automatically selected based on the RGB Quantization
Range bits (Q0, Q1) in the AVI infoframe. If no AVI infoframe is available, RGB quantization
range is selected based on video format according to CEA-861-E.
Full: Full quantization range. The R, G, B quantization range includes all code values (0 -
255). This is defined in CEA-861-E.
Limited: Limited Quantization Range. R, G, B quantization range that excludes some code
values at the extremes (16 - 235). This is defined in CEA-861-E.
Example:
Video Output HDMI 1 RGBQuantizationRange: Full
Video Output HDMI [1,2] CEC Mode
The HDMI outputs support Consumer Electronics Control (CEC). When set to on (default is
off), and the monitor connected to the HDMI output is CEC compatible and CEC is configured,
the system will use CEC to set the monitor in standby when the system enters standby.
Likewise the system will wake up the monitor when the system wakes up from standby. Please
note that the different manufacturers uses different marketing names for CEC, for example
Anynet+ (Samsung); Aquos Link (Sharp); BRAVIA Sync (Sony); HDMI-CEC (Hitachi); Kuro Link
(Pioneer); CE-Link and Regza Link (Toshiba); RIHD (Onkyo); HDAVI Control, EZ-Sync, VIERA Link
(Panasonic); EasyLink (Philips); and NetCommand for HDMI (Mitsubishi).
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable CEC control.
On: Enable CEC control.
Example:
Video Output HDMI 1 CEC Mode: Off
