IP Configuration: RIPv2
Access Lists
407 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
17
• Source IPv4 Address—Enter the source IPv4 address. The following options are
available:
- Any—All IP addresses are included.
- User Defined—Enter an IP address.
• Source IPv4 Mask—Enter the source IPv4 address mask type and value. The following
options are available:
- Network Mask—Enter the network mask.
- Prefix Length—Enter the prefix length.
• Action—Select an action for the access list. The following options are available:
- Permit—Permit entry of packets from the IP address(es) in the access list.
- Deny—Reject entry of packets from the IP address(es) in the access list.
STEP 3 Click Apply. The settings are written to the Running Configuration file.
Source IPv4 Access List
To populate an access list with IP addresses.
STEP 1 Click IP Configuration > > IPv4 Management and Interfaces > Access List > Source IPv4
Address List.
STEP 2 To modify the parameters of an access list, click Add and modify any of the following fields:
• Access List Name—Name of the access list.
• Source IPv4 Address—Source IPv4 address. The following options are available:
- Any—All IP addresses are included.
- User Defined—Enter an IP address.
• Source IPv4 Mask—Source IPv4 address mask type and value. The following options
are available:
- Network Mask—Enter the network mask (for example 255.255.0.0).
- Prefix Length—Enter the prefix length.
• Action—Action for the access list. The following options are available:
