Cisco SX10 - Tour the Remote Control (II)

7
D1509707 User Guide
Cisco TelePresence TRC 6
Produced: April 2016 for CE 8.1
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
Microphone mute/
unmute is the right
circular key.
The Keypad is used to dial
someone or input numerals.
There is a raised bump on
digit 5 to identify the keys.
The key below the
Mute key is the Reject
incoming call / End
call / Cancel /
Back to Home screen
(outside calls).
The key below the Go
back is the green
Call button / Accept
incoming call.
