DIMM Population
Recommended DIMM Populations
Table 23 shows the recommended DIMM slot populations.
If 4 GB DIMMs are mixed with 8 GB or 16 GB DIMMs, the DIMM slots are populated as shown in Table 24.
Table 23 Recommended DIMM Population
DIMMs per
Channel
DIMMs in Each
Channel
1-CPU Memory Size 2-CPU Memory Size DIMM Speed
1
8 GB 24 48 1600 MHz
16 GB 48 96 1600 MHz
32 GB 96 192 1600 MHz
2
4 GB + 4 GB 24 48 1600 MHz
8 GB + 8 GB 48 96 1600 MHz
16 GB + 16 GB 96 192 1600 MHz
4 GB + 8 GB 36 72 1600 MHz
4 GB + 16 GB 60 GB 120 GB 1600 MHz
8 GB + 16 GB 72 GB 144 GB 1600 MHz
32 GB + 32 GB 192 GB 384 GB 160 MHz
Table 24 4 GB DIMMs Mixed with 8 GB or 16 GB DIMMs
Total
Memory
(GB)
Number
of CPUs
CPU 1 DIMM Size (GB) Populated CPU 2 DIMM Size (GB) Populated
B0 B1 C0 C1 D0 D1 F0 F1 G0 G1 H0 H1
12/20 1 4 8/16 none none none none none none none none none none
24/40 4 4 8/16 8/16 none none none none none none none none
20/28 4 4 4 4 none none none none none none none none
16 4 4 4 4 none none none none none none none none
32/48 4 4 4 4 8/16 8/16 none none none none none none
28/36 4 4 4 4 4 8/16 none none none none none none
