Cisco UCS C220 M3 Spec Sheet

Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
CONFIGURING the SERVER
13
STEP 2 SELECT CPU(s)
The standard CPU features are:
■ Intel Xeon E5-2600 v2 and E5-2600 series processor family CPUs (see the following link for
instructions on how to upgrade your server from Intel Xeon E5-2600 to Intel Xeon E5-2600 v2
CPUs:
http://preview.cisco.com/en/US/docs/unified_computing/ucs/c/CPU/IVB/install/IVB-C.html
■ Intel C600 series chipset
■ Cache size of up to 30 MB
Select CPUs
The available CPUs are listed in Ta b l e 3.
Table 3 Available Intel CPUs: E5-2600 and E5-2600 v2 Series Processor Family CPUs
Product ID (PID)
Intel
Number
Clock
Freq
(GHz)
Power
(W)
Cache
Size
(MB)
Cores QPI
Highest DDR3
DIMM Clock
Support
(MHz)
1
Intel Xeon E5-2600 v2
UCS-CPU-E52697B E5-2697B v2 2.70 130 30 12 8 GT/s 1866
UCS-CPU-E52695B E5-2695B v2 2.40 115 30 12 8 GT/s 1866
UCS-CPU-E52690B E5-2690B v2 3.00 130 25 10 8 GT/s 1866
UCS-CPU-E52680B E5-2680B v2 2.80 115 25 10 8 GT/s 1866
UCS-CPU-E52670B E5-2670B v2 2.50 115 25 10 8 GT/s 1866
UCS-CPU-E52667B E5-2667B v2 3.30 130 25 8 8 GT/s 1866
UCS-CPU-E52660B E5-2660B v2 2.20 95 25 10 8 GT/s 1866
UCS-CPU-E52650B E5-2650B v2 2.60 95 20 8 8 GT/s 1866
UCS-CPU-E52640B E5-2640B v2 2.00 95 20 8 7.2 GT/s 1600
UCS-CPU-E52637B E5-2637B v2 3.50 130 15 4 8 GT/s 1866
UCS-CPU-E52630B E5-2630B v2 2.60 80 15 6 7.2 GT/s 1600
UCS-CPU-E52620B E5-2620B v2 2.10 80 15 6 7.2 GT/s 1600
UCS-CPU-E52643B E5-2643B v2 3.50 130 25 6 8 GT/s 1866
UCS-CPU-E52650LB E5-2650LB v2 1.70 70 25 10 8 GT/s 1600
UCS-CPU-E52630LB E5-2630LB v2 2.40 60 15 6 7.2 GT/s 1600
UCS-CPU-E52609B E5-2609B v2 2.50 80 10 4 6.4 GT/s 1333

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
