Cisco UCS C220 M3 - Order Power Supply

Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
CONFIGURING the SERVER
29
STEP 5 SELECT HARD DISK DRIVES (HDDs)
The standard disk drive features are:
■ 3.5-inch large form factor
■ Hot-pluggable
■ Sled-mounted
Select Drives
The available drives are listed in Ta bl e 10.
Table 10 Available Hot-Pluggable Sled-Mounted HDDs
Product ID (PID) PID Description
Drive
Type
Capacity
HDDs
UCS-HD4T7KS3-E 4 TB SAS 7.2K RPM 3.5 inch HDD SAS 4 TB
UCS-HDD3TI2F214 3 TB SAS 7.2K RPM 3.5 inch HDD SAS 3 TB
UCS-HDD2TI2F213 2 TB SAS 7.2K RPM 3.5 inch HDD SAS 2 TB
UCS-HDD1TI2F212 1 TB SAS 7.2K RPM 3.5 inch HDD SAS 1 TB
NOTE: When creating a RAID volume, follow these guidelines:
■ Use the same capacity for each drive in the volume
■ Use either all SAS drives or all SATA drives
■ Use either all HDDs or all SSDs
