Cisco UCS C220 M3 Spec Sheet

Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
28
CONFIGURING the SERVER
Caveats
■ Note that only a single Cisco VIC card (the half-height Cisco VIC 1225 or 1285 PCIe card) is
supported and it must be installed in the full-height PCIe slot (slot 1) on riser 1. So take this
into account when populating RAID controller cards.
■ You can choose an optional RAID configuration (RAID 0, 1, 5, 6, or 10), which is
preconfigured at the factory. The RAID level you choose must be an available RAID choice for
the controller selected. RAID levels 50 and 60 are supported, although they are not available
as configuration options.
Notes . . .
1. Never disable OPROM for the mezzanine slot if the mezzanine card is present, or the system will not boot. If
you remove the mezzanine card and disable its OPROM, you can boot from another bootable device (RAID card,
embedded RAID, or from SAN via an HBA or CNA card). When you boot from a device, make sure its OPROM is
enabled, it is in the proper boot sequence, and its BIOS is configured for a bootable device.
2. If you want to boot from a device other than the 9271-8i or 9271CV-8i MegaRAID PCIe card, you can leave the
card installed. Just disable the OPROM for its slot, and the system will boot even with the card installed.
3. Dual RAID controllers are not supported in this server
4. External RAID card is the 9285CV-8e or 9286CV-8e. Any of these cards can be installed simultaneously with one
mezzanine RAID controller card. It cannot be used simultaneously with an internal RAID controller card
(9271-8i or 9271CV-8i) because of mounting space limitations for the supercap (there is space to mount only
one supercap).
5. A = available slot, O = occupied slot, U = unsupported slot (slot 2 is not supported in 1-CPU systems)
6. The mezzanine slot is not supported in 1-CPU systems
NOTE: RAID for the external RAID controllers (LSI MegaRAID SAS 9286CV-e and LSI
MegaRAID SAS 9285CV-e) is not factory configured.
NOTE: For more important information regarding RAID support, see RAID Details,
page 66 and RAID Option ROM (OPROM) Settings, page 67.

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
