Cisco UCS C220 M3 Spec Sheet

Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
CONFIGURING the SERVER
27
Approved Configurations
The C220 M3 LFF server has a 4-drive backplane.
■ LSI ROM1 and LSI ROM15 embedded RAID upgrade options support up to 4 drives.
■ Mezzanine card (UCSC-RAID-11-C220) supports up to 4 drives.
■ Mezzanine card (UCSC-RAID-MZ-220) supports up to 4 drives.
■ SAS 9271-8i and 9271CV-8i PCIe cards support up to 4 drives.
■ LSI MegaRAID SAS 9285CV-8e and 9286CV-8e PCIe cards support up to 8 external SAS ports
(240 external drives).
See Ta b le 9 for a summary of the supported RAID configuration options.
NOTE: If you do not select a mezzanine card, a PCIe RAID controller, or one of the
embedded RAID upgrade options, you will have an embedded SATA-only RAID
controller that supports up to four SATA-only drives (RAID 0, 1, 10)
Table 9 Supported RAID Configurations
Server
#
CPUs
Embedded
RAID
Mezz
RAID
1
Internal
PCIe RAID
#1
2
Internal
PCIe
RAID #2
3
External
PCIe
RAID
4
# Drives
Supported
PCIe Slots
5
1 2
C220 M3 LFF 1 Enabled
Not
allowed
6
Not
allowed
Not
allowed
Not
allowed
4 internal A U
C220 M3 LFF 1
Not
allowed
Not
allowed
Installed
slot 1
(default)
Not
allowed
Not
allowed
4 internal O U
C220 M3 LFF 1
Not
allowed
Not
allowed
Not
allowed
Not
allowed
Installed
slot 1
240
external
O U
C220 M3 LFF 2 Enabled
Not
allowed
Not
allowed
Not
allowed
Not
allowed
4 internal A A
C220 M3 LFF 2
Not
allowed
Installed
Not
allowed
Not
allowed
Card
absent
4 internal A A
C220 M3 LFF 2
Not
allowed
Not
allowed
Installed
slot 2
(default)
Not
allowed
Not
allowed
4 internal A O
C220 M3 LFF 2
Not
allowed
Card
absent
Not
allowed
Not
allowed
Installed
slot 1 or
slot 2
240
external
A A
C220 M3 LFF 2
Not
allowed
Installed
Not
allowed
Not
allowed
Installed
slot 1 or
slot 2
4 internal
240
external
A A

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
