Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
26
CONFIGURING the SERVER
Super Capacitor Option
UCS-RAID-CV-SC= LSI CacheVault Power Module. This is a spare supercapacitor. It is the exact
same supercapacitor that ships with the 9271CV-8i, 9285CV-8e, and 9286CV-8e
cards listed earlier in this table and can be used as a replacement or upgrade
part.
RAID Configuration Options (not available for embedded RAID)
R2XX-SRAID0 Enable Single Disk Raid 0 Setting (for the following PIDs only):
■ UCS-RAID9271-8i or UCS-RAID9271CV-8I
■ UCSC-RAID-11-C220
■ UCSC-RAID-MZ-220
R2XX-RAID0 Factory preconfigured RAID striping option
Enable RAID 0 Setting. Requires a minimum of one hard drive.
R2XX-RAID1 Factory preconfigured RAID mirroring option
Enable RAID 1 Setting. Requires exactly two drives with the same size, speed,
capacity.
R2XX-RAID5 Factory preconfigured RAID option
Enable RAID 5 Setting. Requires a minimum of three drives of the same size,
speed, capacity.
R2XX-RAID6 Factory preconfigured RAID option
Enable RAID 6 Setting. Requires a minimum of four drives of the same size,
speed, capacity.
R2XX-RAID10 Factory preconfigured RAID option
Enable RAID 10 Setting. Requires a even number of drives (minimum of four
drives) of the same size, speed, capacity.
1. The SAS 9285CV-8e is compatible with PCI Express 2.0 x8 and the 9271-8i, 9271CV-8i, and 9286CV-8e
are compatible with PCI Express 3.0 x8.
NOTE: The 9266CV-8i and 9285CV-8e RAID controllers will reach end-of-life (EOL) in
November, 2013. After then, they will no longer be available.
NOTE: Although RAID levels 50 and 60 are not orderable from the factory, they are
supported for selected controllers as shown in
Tab l e 6
Table 8 Available PCIe RAID Controller Options (continued)
Product ID (PID) PID Description
