Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
CONFIGURING the SERVER
25
UCS-RAID-9285CV-E or
UCS-RAID9286CV-8E
LSI MegaRAID SAS 9285CV-8e or 9286CV-8e (RAID 0, 1, 5, 6, 10)
■ Supports from one to eight external SAS ports (up to 240 external drives).
■ Includes an chassis-mount (remote) supercapacitor to power on-board
1 GB flash-backed write cache.
■ Factory-configured RAID options: RAID 0, 1, 5, 6, 10 (see the RAID
Configuration section in this table). Note that factory RAID configuration is
not available for these controllers, because the factory does not control
the storage array attached to them.
Table 8 Available PCIe RAID Controller Options (continued)
Product ID (PID) PID Description
NOTE: For SAS 9285CV-8e or 9286CV-8e external drive enclosure
support, see the compatibility list (enclosure section) at the following
link:
http://tinyurl.com/b4etshk
Cisco is able to support customers with questions related to the SAS
9285CV-8e or 9286CV-8e RAID card; however, customers should contact
their storage vendor for technical support related to enclosure/JBOD.
