Cisco UCS C220 M3 - Select PCIe Option Cards

Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
24
CONFIGURING the SERVER
UCSC-RAID-11-C220 Cisco UCSC RAID SAS 2008M-8i Mezzanine Card (RAID 0, 1, 5, 10, and 50
supported), operating at 6 Gbs.
■ Supports up to eight internal SAS+SATA drives (limited to four drives for
the C220 M3 LFF chassis). SAS and SATA drives can be mixed.
■ Factory-configured RAID options available: RAID 0, 1, 5, and 10 (see the
RAID PIDs section in this table)
■ No data cache backup
UCSC-RAID-MZ-220 Cisco UCSC RAID SAS 2008M-8i Mezzanine Card (RAID 0, 1, 10 supported),
operating at 6 Gbs.
■ Supports up to eight internal SAS+SATA drives (limited to four drives for
the C220 M3 LFF chassis). SAS and SATA drives can be mixed.
■ Factory-configured RAID options available: RAID 0, 1, and 10 (see the RAID
PIDs section in this table)
■ No data cache backup
Table 8 Available PCIe RAID Controller Options
Product ID (PID) PID Description
RAID Controllers
1
Note that PCIe RAID controllers are installed by default in slot 1 for 1-CPU systems and slot 2 for
2-CPU systems)
UCS-RAID9271-8I or
UCS-RAID9271CV-8I
LSI MegaRAID SAS 9271-8i or 9271CV-8i RAID controller card with data cache
backup (RAID 0, 1, 10, 5, 6, 50, 60), operating at 6 Gbs.
■ Supports up to eight internal SAS+SATA drives (limited to four drives for
the C220 M3 LFF chassis). SAS and SATA drives can be mixed.
■ Includes a 1 GB Transportable Flash Module (TFM) and a chassis-mounted
(remote) supercapacitor for data cache power backup (supercapacitor not
available on the 9271-8i)
■ Factory-configured RAID options available: RAID 0, 1, 5, 6, and 10, (see
the RAID PIDs section in this table)
Table 7 Available Mezzanine Card RAID Options (continued)
Product ID (PID) PID Description
