Cisco UCS C220 M3 - Supported DIMM Populations

Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
64
SUPPLEMENTAL MATERIAL
Additional DIMM Populations
The list in Ta b l e 36 is not a complete list of all supported DIMM populations, but highlights common
configuration options.
Table 36 Supported DIMM Configurations
CPU 1 DIMMs
Total DIMMs
for CPU 1
CPU 1
Capacity
CPU 2 DIMMs
To t al DI M Ms
for CPU 2
CPU 2
Capacity
To t al
Capacity for
2 CPUs
1 x 8 GB 1 8 GB 1 x 8 GB 1 8 GB 16 GB
1 x 16 GB 1 16 GB 1 x 16 GB 1 16 GB 32 GB
2 x 4 GB 2 8 GB 2 x 4 GB 2 8 GB 16 GB
4 x 4 GB 4 16 GB 4 x 4 GB 4 16 GB 32 GB
2 x 8 GB 2 16 GB 2 x 8 GB 2 16 GB 32 GB
6 x 4 GB 6 24 GB 6 x 4 GB 6 24 GB 48 GB
8 x 4 GB 8 32 GB 8 x 4 GB 8 32 GB 64 GB
4 x 8 GB 4 32 GB 4 x 8 GB 4 32 GB 64 GB
8 x 4 GB 8 32 GB 8 x 4 GB 8 32 GB 64 GB
1 x 32 GB 1 32 GB 1 x 32 GB 1 32 GB 64 GB
5 x 8 GB 5 40 GB 5 x 8 GB 5 40 GB 80 GB
3 x 16 GB 3 48 GB 3 x 16 GB 3 48 GB 96 GB
6 x 8 GB 6 48 GB 6 x 8 GB 6 48 GB 96 GB
4x8 GB + 4x4 GB 8 48 GB 4x8 GB + 4x4 GB 8 48 GB 96 GB
7 x 8 GB 7 56 GB 7 x 8 GB 7 56 GB 112 GB
4 x 16 GB 4 64 GB 4 x 16 GB 4 64 GB 128 GB
8 x 8 GB 8 64 GB 8 x 8 GB 8 64 GB 128 GB
2 x 32 GB 2 64 GB 2 x 32 GB 2 64 GB 128 GB
5 x 16 5 80 GB 5 x 16 5 80 GB 160 GB
4x16 GB + 4x4 GB 8 80 GB 4x16 GB + 4x4 GB 8 80 GB 160 GB
6 x 16 GB 6 96 GB 6 x 16 GB 6 96 GB 192 GB
4x8 GB + 4x16 GB 8 96 GB 4x8 GB + 4x16 GB 8 96 GB 192 GB
3 x 32 GB 3 96 GB 3 x 32 GB 3 96 GB 192 GB
7 x 16 GB 7 112 GB 7 x 16 GB 7 112 GB 224 GB
8 x 16 GB 8 128 GB 8 x 16 GB 8 128 GB 256 GB
4 x 32 GB 4 128 GB 4 x 32 GB 4 128 GB 256 GB
8 x 32 GB 8 256 GB 8 x 32 GB 8 256 GB 512 GB
