Cisco UCS C220 M3 Spec Sheet

Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Large Form Factor Hard Disk Drive Model)
CONFIGURING the SERVER
35
Table 14 PCIe Card Compatibility
PCIe Cards
Twinax
Cables
Cisco SFP Modules
SFP-10G-SR DS-SFP-FC8G-SW
Converged Network Adapters (CNAs)
UCSC-PCIE-BSFP
(Broadcom 57712 Dual Port 10Gb SFP+ w/TOE iSCSI)
Yes Yes No
UCSC-PCIE-CSC-02
(Cisco VIC 1225 Dual Port 10Gb SFP+ CNA)
No Yes No
UCSC-PCIE-C10T-02
(Cisco VIC 1225T Dual Port 10GBaseT CNA)
Yes No No
UCSC-PCIE-C40Q-02
(Cisco VIC 1285 Dual Port 40Gb QSFP CNA)
Yes
No
1
No
UCSC-PCIE-C40Q-03
(Cisco VIC 1385 Dual Port 40Gb QSFP+ CNA w/RDMA)
Yes
No
1
No
UCSC-PCIE-ESFP
(Emulex OCe11102-FX dual-port 10 GbE FCoE CNA (Gen 3 CNA))
Yes Yes No
UCSC-PCIE-QSFP
(QLogic QLE8242-CU dual-port 10 GbE FCoE CNA)
Yes Use Qlogic SFP
UCSC-PCIE-B3SFP
(Broadcom 57810 10Gb A-FEX SFP+
Yes Yes No
UCSC-PCIE-Q8362
(Qlogic QLE8362 dual-port 10 GbE FCoE CNA)
Yes Use Qlogic SFP
UCSC-PCIE-E14102
(Emulex OCe14102-UX dual-port 10 GbE FCoE CNA)
Yes Yes No
Network Interface Cards (NICs)
N2XX-ABPCI01-M3
(Broadcom 5709 Dual-Port Ethernet PCIe Adapter for M3
Servers)
Yes No No
N2XX-ABPCI03-M3
(Broadcom 5709 Quad Port 10/100/1Gb NIC w/TOE iSCSI for M3
Servers
Use RJ45 Ethernet cable
N2XX-AIPCI01
(Intel X520 Dual Port 10Gb SFP+ Adapter)
Yes Use Intel SFP
UCSC-PCIE-ITG
(Intel X540 Dual Port 10GBase-T Adapter)
Yes No No
UCSC-PCIE-IRJ45
(Intel i350 Quad Port 1Gb Adapter
Use RJ45 Ethernet cable
UCSC-PCIE-BTG
(Broadcom 57712 Dual Port 10GBASE-T w/TOE iSCSI)
Yes No No
Host Bus Adapters (HBAs)
N2XX-AEPCI03
(Emulex LPe 11002 Dual Port 4Gb Fibre Channel HBA
No Preinstalled - do not change SFP
N2XX-AEPCI05
(Emulex LPe 12002 Dual Port 8Gb Fibre Channel HBA)
No Preinstalled - do not change SFP
N2XX-AQPCI03
(QLogic QLE2462 Dual Port 4Gb Fibre Channel HBA)
No Preinstalled - do not change SFP

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100
