Cisco UCS C240 M4 Service Manual

D-4
Cisco UCS C240 M4 Server Installation and Service Guide
OL-32474-01
Appendix D GPU Card Installation
Replacing a GPU Card (Less Than 300 W)
• Use this section to install or replace a GPU card that draws less than 300 W power. Use this section
to install the following GPUs:
– GRID K1
– GRID K2
– Tesla K10
– Tesla K20
– Tesla K20X
– Tesla K40
• For the 300 W GPU cards (Tesla K80 and Tesla M60), see:
– Installing an NVIDIA K80 GPU Card and 300 W GPU Conversion Kit, page D-6
– Installing a Tesla M60 GPU Card and 300 W GPU Conversion Kit, page D-13
Step 1 Shut down and power off the server as described in Shutting Down and Powering Off the Server,
page 3-9.
Step 2 Slide the server out the front of the rack far enough so that you can remove the top cover. You might have
to detach cables from the rear panel to provide clearance.
Caution If you cannot safely view and access the component, remove the server from the rack.
Step 3 Remove the top cover as described in Removing and Replacing the Server Top Cover, page 3-10.
Step 4 Remove the PCIe risers and any existing GPU card:
a. Lift straight up on both ends of the riser to disengage its circuit board from the socket on the
motherboard. Set the riser on an antistatic mat.
b. On the bottom of the riser, loosen the single thumbscrew that holds the securing plate. See
Figure 3-28.
c. Swing open the securing plate and remove it from the riser to provide access.
d. Swing open the card-tab retainer that secures the back-panel tab of the card (see Figure 3-28).
e. Pull evenly on both ends of the GPU card to disengage it from the socket on the PCIe riser (or
remove a blanking panel) and then set the card aside.
Note See GPU Card Configuration Rules, page D-2 before you install the GPU cards to the risers. Slot
population restrictions apply.
Step 5 Install your first GPU card into PCIe slot 2 or slot 5. See Figure 3-27 for the riser and slot locations.
Note GPU cards are not supported in PCIe riser 1 version 1B (UCSC-PCI-1B-240M4) or 1C
(UCSC-PCI-1C-240M4). Use riser 1 version 1A (slot 2) or riser 2 (slot 5) for GPU cards.
a. Align the GPU card with the socket on the riser, and then gently push the card’s edge connector into
the socket. Press evenly on both corners of the card to avoid damaging the connector.
b. Connect the GPU card power cable into the GPU card and into the GPU POWER connector on the
PCIe riser (see Figure 3-28).

Cisco UCS C240 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
Processor model	E5-2650V3
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Embedded options available	No
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60
Total storage capacity	- GB
Maximum storage capacity	- TB
Number of HDDs installed	-
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
LAN controller	Intel® I350
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux Oracle Solaris Ubuntu Server CentOS
Chassis type	Rack (2U)
Power supply input frequency	50 - 60 Hz
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Trusted Platform Module (TPM) version	1.2
PCI Express slots version	3.0

Weight and Dimensions

Depth	738 mm
Width	448 mm
Height	87 mm
