c. Return the securing plate to the riser. Insert the two hinge-tabs into the two slots on the riser, and
then swing the securing plate closed.
d. Tighten the single thumbscrew that holds the securing plate.
e. Close the card-tab retainer (see Figure 3-28).
f. Position the PCIe riser over its socket on the motherboard and over its alignment features in the
chassis (see Figure 3-26).
g. Carefully push down on both ends of the PCIe riser to fully engage its circuit board connector with
the socket on the motherboard.
Step 6 Replace the top cover.
Step 7 Replace the server in the rack, replace cables, and then power on the server by pressing the Power button.
Step 8 Continue with Installing Drivers to Support the NVIDIA GPU Cards, page D-31.
