Cisco UCS S3260 Service Manual

3-5
Cisco UCS S3260 Storage Server Chassis Installation and Service Guide
Chapter 3 Maintaining the System
Status LEDs and Buttons
Table 3-2 Rear-Panel LED States
LED Name State
1 Server node power button/LED
• Off—There is no AC power to the server node. It is safe to remove the server
node from the chassis.
• Amber—The server node is in standby power mode. Power is supplied only to
the Cisco IMC. It is safe to remove the server node from the chassis.
• Green—The server node is in main power mode. Power is supplied to all server
node components.
2 Server node unit identification
button/LED
• Off—The Identification LED is not in use.
• Blue—The Identification LED is activated.
3 1 Gb Ethernet port link speed
LED (on each M5 server node
only)
• Off—Link speed is 10/100 Mbps.
• Green—Link speed is 1 Gbps.
4 1 Gb Ethernet port link activity
LED (on each M5 server node
only)
• Off—No link is present.
• Green—Link is present, no activity.
• Green, blinking—Link is present, with activity.
5 Power supply status (on each
power supply unit)
AC Power Supplies:
• Off—No AC power input.
• Green, steady—The power supply is operating normally and supplying DC
power to the system.
• Green, blinking—AC power is OK, DC output not enabled (standby mode).
• Amber, blinking—An event warning threshold has been reached, but the power
supply continues to operate.
• Amber, steady—A critical fault threshold has been reached, causing the power
supply to shut down.
DC Power Supplies:
• Off—No DC input (12 V main power off, 12 V standby power off).
• Green, steady—The power supply is operating normally and supplying DC
power to the system (12 V main power on).
• Green, blinking—DC output not enabled (12 V main power off; 12 V standby
power on).
• Amber, blinking—An event warning threshold has been reached, but the power
supply continues to operate with 12 V main power.
• Amber, steady—A critical fault threshold has been reached, causing the power
supply to shut down (for example, over-current, over-voltage or
over-temperature failure)
6 QSFP port link LED
• Off—No link.
• Green—Link present.
7 QSFP port activity LED
• Off—No link is present.
• Green—Link is present, but no activity.
• Green, blinking—Link is present with activity.

Cisco UCS S3260 Specifications

General

Drive Bays	Up to 56
Maximum Storage Capacity	Up to 600 TB
Power Supply	Up to 4 hot-plug power supplies
Product Type	Storage Server Chassis
Supported Drives	SAS, SATA
Processors	Up to two Intel Xeon Scalable processors
Memory	Up to 1.5 TB DDR4 RAM
Power Supplies	Redundant 80+ Platinum power supplies
Total Drive Bays	56
Management	Cisco UCS Manager
Compatibility	Cisco UCS system
Form Factor	4U rack
