System Health Monitoring
Run a System Baseline for Environmental Resources
107
Best Practice User Guide for the Catalyst 3850 and Catalyst 3650 Switch Series
This example shows that crash files were created in the directory.
Run a System Baseline for Environmental Resources
Step 7 Use the show environment command to display an overview of switch health.
It is important to monitor environmental resource values because something as small as a fan failure can
lead to a serious hardware problem. If your switches provide Power Over Ethernet (POE), then the show
environment command will also provide a view into the power supplies and if they are performing as
expected.
Step 8 If your switches are in a stack, run the show environment stack command to view all of the
environmental outputs stack wide.
Although some of settings are adjustable, we recommend leaving the settings with their default values.
dir crashinfo
Directory of crashinfo:/
6073 drwx 1024 Jul 17 2013 17:53:48 +00:00 ap_crash
12 -rwx 0 Jan 1 1970 00:00:06 +00:00 koops.dat
11 -rwx 357 Jun 1 2014 13:05:15 +00:00 last_systemreport_log
13 -rwx 1128623 Nov 22 2013 12:33:27 +00:00
system-report_2_20131122-123229-UTC.gz
14 -rwx 39 Jun 1 2014 13:05:15 +00:00 last_systemreport
15 -rwx 657766 Jun 5 2013 09:17:03 +00:00
system-report_1_20130605-091616-UTC.gz
16 -rwx 737390 Jun 26 2013 22:48:22 +00:00
system-report_1_20130626-224726-UTC.gz
show environment all
Switch 1 FAN 1 is OK
Switch 1 FAN 2 is OK
Switch 1 FAN 3 is OK
FAN PS-1 is OK
FAN PS-2 is OK
Switch 1: SYSTEM TEMPERATURE is OK
SW PID Serial# Status Sys Pwr PoE Pwr Watts
-- ------------------ ---------- --------------- ------- ------- -----
1A PWR-C1-715WAC LIT171310MT OK Good Good 715
1B PWR-C1-715WAC LIT171310PS OK Good Good 715
