LEDs
You can use the switch system and port LEDs to monitor switch activity and performance.
Figure 4: Switch LEDs
PoE LED
1
4SYST LED (system)1
Console LED5STAT LED (status)2
Port LEDs6SPEED LED3
1
Only on switch models that support PoE.
Cisco Catalyst 2960-L Series 24-Port and 48-Port Switch Hardware Installation Guide
6
Product Overview
LEDs
