A loop (for the optional power cord retainer)
•
Heat sink fins (PoE models only)
Figure 5: Rear Panel of a Non-PoE Switch
A loop (for the optional power cord
retainer)
3Security Slot1
An AC power connector2
Figure 6: Rear Panel of a PoE Switch
A loop (for the optional power cord
retainer)
3Security Slot1
Heat sink fins4An AC power connector2
Cisco Catalyst 2960-L Series 24-Port and 48-Port Switch Hardware Installation Guide
9
Product Overview
Rear Panel
