Cisco WS-C2960L-24TS-LL User Manual

Console DeviceRJ-45-to-DB-9 Terminal AdapterSwitch Console Port (DTE)
SignalDB-9 PinSignal
TxD3RxD
DTR4DSR
RTS7CTS
Table 4: Console Port Signaling with a DB-25 Adapter
Console DeviceRJ-45-to-DB-25 Terminal AdapterSwitch Console Port (DTE)
SignalDB-25 PinSignal
CTS5RTS
DSR6DTR
RxD3TxD
GND7GND
GND7GND
TxD2RxD
DTR20DSR
RTS4CTS
Cisco Catalyst 2960-L Series 24-Port and 48-Port Switch Hardware Installation Guide
50
Connector and Cable Specifications
Console Port Adapter Pinouts
