Chapter5
Appendixes
Specifications
Printing mode Serial impact dot matrix
Printing direction Bi-directional
Head pins 9 pins (φ: 0.3mm, Pin interval; 1/72inch)
Printing line columns
Paper width of 76.2mm 40/42 or 33/35 columns
Paper width of 69.5mm 36/40 or 30/32 columns
Paper width of 57.5mm 30/33 or 25/27 columns
200/400 dots (full dot/including half dot)
Font configuration 7Ω9 or 9Ω9 dots
Character types ASCII (96 characters), International characters, Katakana
Code pages:
437, KATAKANA, 850, 860, 863, 865, 852, 866, 857, 858, WPC1252
Panel/switches 1 switch (FEED), 3 LED (POWER/PAPER OUT/ERROR), 1 buzzer
Printing speed Printing: 240CPS (3P paper 200CPS)
Through-put: 76.2mm wide, 40 columns (7Ω9+3sp, 6LPI) 5.0LPS
69.5mm wide, 36 columns (7Ω9+3sp, 6LPI) 5.4LPS
57.5mm wide, 30 columns (7Ω9+3sp, 6LPI) 6.0LPS
Paper feed Friction feed
Minimum pitch: 1/144 inch
Paper feed speed: 40LPS (6LPI)
Paper Types: 1P roll paper
2P copy roll paper (1 original + 1 copy)
3P copy roll paper (1 original + 2 copies)
* When 3P, printing speed falls 16%
Paper widths: 76.2 / 69.5 / 57.5 (±0.5)mm
Roll diameter: φ30mm to φ83mm
Core diameter: Interior diameter φ10 mm, exterior diameter φ27mm or less
Paper thickness: 1P 0.06 to 0.085mm
Copy paper 0.05 to 0.20mm (total thickness)
But the total thickness that can be cut is from 0.05 to 0.14mm.
* No glue on the core or end of the paper.
Ribbon Method: special ribbon cassette
Colors: Single color (purple, black), 2 color (black and red)
Life: Purple, approx. 4 million characters (continuous printing at 25°C)
Black, approx. 3 million characters (continuous printing at 25°C)
Red/black, black 1.5 million characters, Red 750,000 characters
Interface Standard model: 2 models, either RS232C or IEEE1284
Emulation ESC/POS (Page mode)
CBM mode, STAR mode
+2
–0
