Citizen CL-S621 User Manual

1
Setup
10
Confirmation of Carton Contents
Note: The empty carton and packing materials should be stored for future
shipping of the printer.
Removing the Packing Material
The printer is shipped with adhesive tape in place to hold the top cover
closed. Simply remove the two pieces of tape on either side of the top cover.
Then simply open the cover by lifting up and tipping it backwards.
There is another strip of adhesive tape that must be removed which holds
the mechanism closed for shipping. Remove the tape and attached paper by
carefully peeling from the plastic case.
Retain the tape should you need to transport the printer again.
CD-ROM
Quick-start Guide
Media holder barMedia holder guide
Head cleaner
Paper CoreSample RibbonRibbon Holder
Te st label media Power cord
Printer
CL-S521, CL-S621 & CL-S631
Thermal Transfer Barcode & Label Printer
Q
UICK-
S
TART
G
UID
E
This Quick-Start Guide covers basic operation.
For detailed operating instructions, please see the User's Manual on the
supplied CD-ROM.
C
L-S
5
2
1
C
L-S
6
2
1
C
L-S
6
3
1
Check that the following accessories are included with the printer
in the carton.

Citizen CL-S621 Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 DPI
RS-232 ports	1
RS-232 interface	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Ethernet, Parallel, Wireless LAN
Connectivity technology	Wired
Flash memory	4 MB
Internal memory	16 MB
Compatible operating systems	Windows, XP, 2003, 2008, Vista, Windows 7
Media thickness	0.0635 - 0.254 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Product color	Gray

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	270 mm
Weight	4500 g
