3
Printer Adjustments
52
Cleaning
Wipe off any foreign matter such as media dust, dirt and adhesive substances
built up around the printhead with the head cleaning pen (head cleaner)
provided, and use a soft cloth soaked in ethyl alcohol for the platen etc.
It is particularly important to clean the thermal printhead after printing on
thermal media for long periods, which will guarantee the print quality and
extend the life of the thermal printhead.
Note: Always use the head cleaner when cleaning the thermal printhead.
Head cleaner
Thermal printhead
Caution
Do not use any solvent other than ethyl alcohol. Solvents such as
benzene, acetone and thinner will dissolve plastic parts and destroy
the thermal printhead, platen and much of the printer!
Try to avoid using "excessive amounts" of ethyl alcohol to clean the
platen. Excessive use will harden the platen surface prematurely.
Platen
Ribbon guide roller
Guide shaft

Other manuals for Citizen CL-S621

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Citizen CL-S621 and is the answer not in the manual?

Citizen CL-S621 Specifications

General IconGeneral
Print technologyDirect thermal / Thermal transfer
Maximum resolution203 DPI
RS-232 ports1
RS-232 interfaceYes
Standard interfacesUSB 1.1, Serial
Optional connectivityEthernet, Parallel, Wireless LAN
Connectivity technologyWired
Flash memory4 MB
Internal memory16 MB
Compatible operating systemsWindows, XP, 2003, 2008, Vista, Windows 7
Media thickness0.0635 - 0.254 mm
Maximum media length1625.6 mm
Maximum roll diameter125 mm
Supported paper width12.5 - 118.1 mm
Product colorGray
Weight and Dimensions IconWeight and Dimensions
Depth289 mm
Width231 mm
Height270 mm
Weight4500 g
